PRODUCT CODE: ET1611-29

Phospho-PDGF Receptor beta (Y740) Recombinant Rabbit Monoclonal Antibody [SN0646] (ET1611-29)

  • Recombinant

Applications

  • WB

  • ICC

  • IF

REACTIVITY

  • Mouse

  • Rat

ICC staining PDGF Receptor beta(phospho Y740) in C2C12 cells (green). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS.
  • ICC staining PDGF Receptor beta(phospho Y740) in C2C12 cells (green). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS.
  • ICC staining PDGF Receptor beta(phospho Y740) in Hela cells (green). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS.
  • ICC staining PDGF Receptor beta(phospho Y740) in L6 cells (green). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS.
ICC staining PDGF Receptor beta(phospho Y740) in C2C12 cells (green). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS.

Applications

  • WB

  • ICC

  • IF

REACTIVITY

  • Mouse

  • Rat

SPECIFICATIONS

Product Type

Recombinant Rabbit monoclonal primary

Product Name

Phospho-PDGF Receptor beta (Y740) Recombinant Rabbit Monoclonal Antibody [SN0646] (ET1611-29)

Immunogen

Synthetic phospho-peptide corresponding to residues surrounding tyr740 of human pdgf receptor beta.

Host

Rabbit

Modification

Phospho

Modification Site

Y740

Positive Control

C2C12, Hela, L6.

Conjugation

Unconjugated

Clonality

Monoclonal

Clone Number

SN0646

PROPERTIES

Form

Liquid

Storage Condition

Store at +4C after thawing. Aliquot store at -20C or -80C. Avoid repeated freeze / thaw cycles.

Storage Buffer

1*TBS (pH7.4), 0.05% BSA, 40% Glycerol. Preservative: 0.05% Sodium Azide.

Concentration

1 ug/ul

PURIFICATION

Protein A purified.

MOLECULAR WEIGHT

190 kDa

Isotype

IgG

APPLICATION DILUTION

  • WB

  • 1:1,000

  • ICC/IF

  • 1:50-1:200

TARGET

UNIPROT #

PROTEIN NAME

Phospho-PDGF Receptor beta (Y740)

SYNONYMS

Beta platelet derived growth factor receptor antibody; Beta-type platelet-derived growth factor receptor antibody; CD 140B antibody; CD140 antigen-like family member B antibody; CD140b antibody; CD140b antigen antibody; IBGC4 antibody; IMF1 antibody; JTK12 antibody; OTTHUMP00000160528 antibody; PDGF R beta antibody; PDGF-R-beta antibody; PDGFR 1 antibody; PDGFR antibody; PDGFR beta antibody; PDGFR1 antibody; PDGFRB antibody; PGFRB_HUMAN antibody; Platelet derived growth factor receptor 1 antibody; Platelet derived growth factor receptor beta antibody; Platelet derived growth factor receptor beta polypeptide antibody

SEQUENCE SIMILARITIES

Belongs to the protein kinase superfamily. Tyr protein kinase family. CSF-1/PDGF receptor subfamily.

TISSUE SPECIFICITY

Weakly expressed in glomerular mesangial cells and interstitial cells. Up-regulated in areas of renal fibrosis. In mice with unilateral ureteral obstruction, increased expression in interstitial cells at day 4 and expression is markedly elevated at day 7 and is maximal at day 14.

POST-TRANSLATIONAL MODIFICATION

Autophosphorylated on tyrosine residues upon ligand binding. Autophosphorylation occurs in trans, i.e. one subunit of the dimeric receptor phosphorylates tyrosine residues on the other subunit. Phosphorylation at Tyr-578, and to a lesser degree, Tyr-580 is important for interaction with SRC. Phosphorylation at Tyr-715 is important for interaction with GRB2. Phosphorylation at Tyr-739 and Tyr-750 is important for interaction with PIK3R1. Phosphorylation at Tyr-750 is important for interaction with NCK1. Phosphorylation at Tyr-770 and Tyr-856 is important for interaction with RASA1/GAP. Phosphorylation at Tyr-856 is important for efficient phosphorylation of PLCG1 and PTPN11, resulting in increased phosphorylation of AKT1, MAPK1/ERK2 and/or MAPK3/ERK1, PDCD6IP/ALIX and STAM, and in increased cell proliferation. Phosphorylation at Tyr-1008 is important for interaction with PTPN11. Phosphorylation at Tyr-1008 and Tyr-1020 is important for interaction with PLCG1. Dephosphorylated by PTPRJ at Tyr-750, Tyr-856, Tyr-1008 and Tyr-1020 (By similarity). Dephosphorylated by PTPN2 at Tyr-578 and Tyr-1020.; N-glycosylated.; Ubiquitinated. After autophosphorylation, the receptor is polyubiquitinated, leading to its degradation.

SUBCELLULAR LOCATION

Cell membrane, Cytoplasmic vesicle.

FUNCTION

Platelet Derived Growth Factor (PDGF) is a mitogen for mesenchyme- and glia-derived cells. PDGF consists of two chains, A and B, which dimerize to form functionally distinct isoforms, PDGF-AA, PDGF-AB, and PDGF-BB. These three isoforms bind with different affinities to two receptor types, a and b, which are endowed with protein tyrosine kinase domains and undergo either homo- or heterodimerization as a consequence of ligand binding. Ligand stimulation of PDGFR-b leads to autophosphorylation at Tyr-857, which is the major autophosphorylation site, and Tyr-751, which is the major in vitro phosphorylation site. Autophosphorylation of Tyr-751, which lies in the kinase insert region, is required for binding of phosphatidylinositol-3 kinase to the receptor. These auto-phosphorylation events largely contribute to signal transduction through the PDGF receptor.
